𝐃𝐰𝐲𝐞𝐫𝐎𝐦𝐞𝐠𝐚: 𝐈𝐧𝐬𝐭𝐚𝐥𝐥𝐚𝐭𝐢𝐨𝐧 𝐁𝐞𝐬𝐭 𝐏𝐫𝐚𝐜𝐭𝐢𝐜𝐞𝘀

Proper installation is crucial for achieving accurate and reliable readings from electromagnetic flow meters. Even high-quality meters can provide poor results if not installed correctly. Key factors include proper grounding, pipeline condition, meter placement, and adherence to manufacturer guidelines.

Installation Methods:

𝟭. 𝗜𝗻-𝗟𝗶𝗻𝗲 𝗜𝗻𝘀𝘁𝗮𝗹𝗹𝗮𝘁𝗶𝗼𝗻 – involves integrating the electromagnetic flow meter directly into the pipeline – replacing a section of the pipe. One example for this is the FMG480 Series Magmeter.

Pros:

• High accuracy and reliability

• No extra fittings needed

• Low maintenance once installed

Cons:

• Requires system shutdown for installation/removal

• Costly for retrofitting existing systems

𝟮. 𝗛𝗼𝘁-𝗧𝗮𝗽 𝗜𝗻𝘀𝘁𝗮𝗹𝗹𝗮𝘁𝗶𝗼𝗻 – a specialized method that allows an electromagnetic flow meter to be inserted into a pressurized pipeline without the need for system shutdown. An example for this is the Series-IEF Electromagnetic Flow Transmitter.

Pros:

• No need to shut down operations

• Suitable for large or pressurized pipes

• Cost-effective for retrofits

Cons:

• Slightly less accurate than in-line methods

• Requires careful drilling and sealing

For more installation guidelines, you can contact us at [email protected] or [email protected].
